As required by the EU Batteries Regulation – (EU) 2023/1542 , this webpage explain instructions and safety information.
This is example of Parts Number purchased through us. Purchase Parts Number is different every Robot & Controller.Please read parts catalogue. But, Battery performance is all belows.
Type: LS17500
Use position: encoder backup battery in robot arm
| Our Purchase Number | Makers Parts Number | DoC |
|---|---|---|
|
50750-0002
50750-0011 50750-0028 50750-0029 50750-0031 50750-0034 50750-0036 50750-0045 50750-0048 50750-0052 50750-1017 50750-C018 |
C10-0420
Capacity: 3.6Ah
Mass: 50.5g |
Website |
| 60750-0010 |
C10-0454
Capacity: 2.6Ah
Mass: 19.5g |
Website |
|
50750-0030 50750-0035 50750-0037 |
C10-0455
Capacity: 3.6Ah
Mass: 54g |
Website |
※ SAFT DoC is available on the SAFT website. The link below already includes each product number in the search field. Please use the download button at the bottom of the page.
|
Battery category :
Industrial
Model identification :
LS17500
Capacity : 3.6Ah *
*Please see each Declaration of Conformity
Weight : 50.5g * |
Li‑SOCl2
|
 |
Hazardous substances contained : SOCl2, Li metal |
 |
Usable extinguishing agent : Class D metal extinguishers on raw lithium metal |
 |
Critical Raw Materials contained > 0.1% : None |
 |
Manufacturer name : Saft, a subsidiary of TotalEnergies 26, quai Charles Pasqua 92300 Levallois‑Perret – France WEB : https://saft4u.saft.com/en
E‑mail : lithiumsales.fr@saft.com |
|
Saft SAS Block 8, 201 LianFeng Rd Free Trade Zone Zhuhai 519030, China |
Date of manufacture: see note below the table. |
Please refer to the external surface of the LS17500 .Finish date code exist in side of battery.
Finish date code = YYMMDDX
YY: Year of manufacture MM: Month of manufacture DD:Day of manufacture
X: Manufacturer-assigned serial code
Type:BR2032
Use position: the main CPU board of controller
| Our Purchase Number | Makers Part Number | DoC |
|---|---|---|
|
60750-0007 60750-1016 |
BR2032/BK |
|
Battery category :
Industrial
Model identification :
BR2032
Capacity : 200mAh
Weight : 2.6g |
Li-CFx2
|
|
|
Hazardous substances contained : 1,2-dimethoxyethane, Li metalLithium |
|
|
Usable extinguishing agent : Alcohol-resistant foam, Dry sand |
|
|
Critical Raw Materials contained > 0.1% : Lithium |
|
|
Manufacturer name : Panasonic Energy Co., Ltd. 1-1, Matsushita-cho, Moriguchi-shi, Osaka 570-8511, Japan WEB : https://energy.panasonic.com/eu/business/inquiry
|
|
PT. Panasonic Gobel Energy Indonesia Kawasan Industri Gobel, Jl. Teuku Umar Km.44 Telaga Asih Cikarang Barat, Bekasi, Jawa Barat, 17530, Indonesia |
Date of manufacture: see note below the table. |
The battery manufacturing date is not marked on the battery surface. The date is available on the manufacturer’s packaging, which is discarded during assembly.Before replacement, use the software initialization date as the reference manufacturing date. After replacement, use the manufacturing date indicated on the manufacturer’s packaging.
If you have a question for our company, please use the “Contact Us” button and enter the following.
Please select “Other” for Nature of Your Inquiry. In the Comments or Questions section, please specify that your inquiry concerns EUBR.
